Cảm biến laser Panasonic LS-H21F

Name: Cảm biến laser Panasonic LS-H21F
Brand: Panasonic
SKU: LS-H21F
Availability: InStock

Panasonic (formerly Sunx) diffuse laser with up to 1 meter sensing distanceFDA Class II LaserSpot size adjust potentiometerRequires LS-400 series amplifier – sold separatelyMounting brackets sold separately2 Meter Cable

8.086.000 ₫

Mã sản phẩm: LS-H21F Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
LS-400
Sensing Mode
Diffuse
Sensing Mode Features
Opaque & Translucent Target Detection
Sensor Body Type
Compact
Sensor Body Feature
Side Screw Mounting
Sensor Type
Amplifier Separate Type
Sensitivity Setting Type
Push Button Teach
Display Type
Digital Display Remote Amp
Sensor Features
Amp separate diffuse laser sensing head with multi-turn adjuster for beam spot control. Beam spot of ø0.2mm at 50mm to a beam spot of ø1mm at 1m Use with LS-400 style digital amplifer.
Laser Beam Spot Size
ø 0.2mm
Laser Light Source Details
Red semiconductor laser, Class 2 (FDA / IEC / JIS) 655nm
Laser Output
3 mW max
Supply Voltage Details
12 to 24 VDC Separate Amp
Setting Distance
30mm to 1 meter
Control Output
NPN or PNP
Output Details
2 each NPN or PNP per Amplifier selected
Output Operation Mode
Light-On/Dark-On selectable
Construction
PBT enclosure, acrylic lens cover
Temperature Rating
-10º to +55º C
Protection Rating
IP40
Connection Type
Quick Disconnect
Connection Detail
Cable 2m with Fixed Connector
Item Weight
0.20 lbs per EA
