Name: HMI Keyence VT5-X10
Brand: Keyence
SKU: VT5-X10
Availability: InStock

Thông số	Giá trị
Model	VT5-X10
General specifications – Current consumption	1300 mA max.
Generalspecifications – Power supply voltage	24 VDC ±20%
Shock resistance – Intermittent vibration – Frequency:5 to 9 Hz	Half amplitude: 3.5 mm*1
Frequency:9 to 150 Hz	Acceleration: 9.8 m/s2*1
Continuous vibration – Frequency:5 to 9 Hz	Half amplitude: 1.75 mm*1
Frequency:9 to 150 Hz	Acceleration: 4.9 m/s2*1
General specifications – Structure	Panel built-in type with IP65f-equivalent enclosure rating; dustproof and waterjet-proof only at front panel*2
Overvoltage category	I
Pollution degree	2
Noise resistance	1500 Vp-p or more, pulse width: 1 µs, 50ns (by noise simulator)
Withstand voltage	1500 VAC for 1 minute (between power terminal and housing)
Insulation resistance	50 MΩ minimum (tested with 500 VDC megohmmeter between power terminal and housing)
Operating environment	No dust or corrosive gas
Ambient operating temperature	0 to +50°C*3
Ambient operating humidity	20 to 85% RH (no condensation)*4
Ambient storage temperature	-20 to +60°C (no freezing)
Ambient storage humidity	20 to 85% RH (no condensation)
Weight	Approx. 1800 g
Performancespecifications – Display panel – Displayed components	TFT LCD
Display colour	16 million colours
Number of pixels	W 1024 × H 768 pixels
Effective display area	W 211.2 × H 158.4 mm
Data backup – Screen data	Flash ROM
Record data	SRAM backup: Primary lithium battery (5 years above of service life at 25°C)
RGB input – Display colour	16 million colours
Signaling system	Analogue RGB
Vertical synchronizationfrequency	XGA (1024 × 768): 60 HzSVGA (800 × 600): 56/60/72/75/85 HzVGA (640 × 480): 60/72/75/85 Hz
DVI-D output – Signaling system	DVI-D
Vertical synchronizationfrequency	60 Hz
Resolution	XGA: W 1024 × H 768 pixels
Performance specifications – Backlightlamp – System	White LED (not replaceable)
Performancespecifications – Backlight – Service life (normal temperature and humidity)	Approx. 50000 h
Performance specifications – Touchswitch – System	Analogue resistive film
Performancespecifications – Touch controlswitch – Operating force	0.98 N or less
Performance specifications – Touchswitch – Life-span	1 million times above
Screen data internal memory – Memory capacity	256 MB
Calendar timer	Accuracy: ±40 s/month (25°C), Backup: Primary lithium battery (5 years above of service life at 25°C)
