Cảm biến tiệm cận Panasonic GX-M8A-Z

Cảm biến tiệm cận Panasonic GX-M8A-Z

“
The GX-M Series of 2 & 3-wire DC Proximity will be discontinued in September of 2022. The last time buy for this part is September, 15th 2022. Order now for your current needs and contact Ramco (800) 280-6933 for best replacement optionsPanasonic (formerly Sunx) Cylindrical Shielded Inductive Proximity SensorM12 4 pin quick disconnect1.2mm stable sensing range – 1.5mm max12 to 24 VDCNPN-normally open (NO)IP67 (IEC)“

960.000 ₫

SKU: GX-M8A-Z Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
GX-M
Self Contained/Amplifier Separate
Self Contained
Mounting Style
Cylindrical Threaded
Features
Shielded Type
Power Supply Details
12 to 24VDC
Diameter/Size
M8
Material
Metal
Housing Material Details
Nickel plated brass, PPS face
Sensing Direction
End Sensing
Mounting Type
Shielded/Flush Mounting
Max Operation Distance
1.5mm
Repeatability
<5% of distance
Hysteresis
<15%
Response Frequency
5 kHz
Output Type
NPN
Output Details
NO
Connection Type
Quick Disconnect
Connection Details
M12 4P QD
Protection
IP67
Temperature Range
-25 to +70 C

Thông tin bổ sung

Thương hiệu	Panasonic
