Cảm biến sợi quang Panasonic FX-MR7

Name: Cảm biến sợi quang Panasonic FX-MR7
Brand: Panasonic
SKU: FX-MR7
Availability: InStock

Extremely fine spot of ø0.1 mm ø0.004 in
approx. achieved.
• Applicable fibers:
FD-R33EG, FD-EG31,
FD-R34EG, FD-R32EG,
FD-EG30, FD-R31G, FD-42G,
FD-42GW, FD-32G, FD-32GX
• Ambient temperature: -55 to +70 °C
+67 to +158 °F

2.076.000 ₫

SKU: FX-MR7 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Add-on Lens
Sensing Mode
Diffuse
Key Attributes
Axial Sensing
Mounting Dimension
Ø 4.3 mm / M3 x 0.5 Internal thread
Fiber Cable Feature
Works with Fiber Cables / (Spot Diameter) FD-EG1 / (Ø 0.1mm), FD-EG30 / (Ø 0.2mm), FD-42G(W) / (Ø 0.4mm), FD-32G(X) / (Ø 0.4mm). Sq Head Fiber FD-R33EG / (Ø 0.1mm), FD-R34EG / (Ø 0.15mm), FD-R32EG / (
Item Weight
0.02 lbs per EA
