| Dòng sản phẩm | FX-500 |
| Tình trạng sản phẩm | Mẫu hiện hành |
| Kiểu cài đặt | PB Teaching |
| Chi tiết kiểu cài đặt | PB Teach with fine adjust |
| Kiểu hiển thị | Màn hình LED kỹ thuật số |
| Chi tiết hiển thị | Dual 4-digit Red/Grn display,LED Status Indicators |
| Đặc điểm nổi bật | Best-In-Class FO amplifier. Ulta long sensing range with high-intensity beam emitted and HYPER mode response even with small diameter fibers. Max accuracy with 3 level hysteresis mode setting |
| Nguồn sáng | LED đỏ |
| Loại bộ khuếch đại | Loại kết nối Master/Slave |
| Loại ngõ ra | PNP |
| Chi tiết ngõ ra | 1 each PNP |
| Kiểu kết nối | Cable w/conn |
| Chi tiết kết nối | Use CN-70 Series Connector/cable |
| Điện áp nguồn cấp | Một chiều (DC) |
| Thông số điện áp | 12 to 24VDC |
| Thời gian đáp ứng nhanh nhất | 22µs |
| Tùy chọn trễ thời gian | Multifunction |
| Tùy chọn bộ đếm | Không |
| Chức năng ngõ vào từ xa | Không |
| Chống nhiễu chéo | Up to 3 units (Main/Sub) |
| Cấp bảo vệ | IP40 |
| Phụ kiện đi kèm | FX-MB1 (amplifier protection seal): 1 set |
| Khối lượng | 0.18 lbs per EA |
Bộ khuếch đại sợi quang Panasonic FX-501P
Super-Fast & Stable Detection of Minute Objects
Max. 25 µs Response Time
FX-500 with its high speed response time will improve your productivity. The FX-500 makes detecting minute objects, when using a small diameter fiber, possible with a super-fast time and longer sensing range.
Key Features:
Panasonic (formerly Sunx) Fiber Optic Amplifier
12 to 24VDCPNP outputDIN rail mount
Red LED light source
Accepts all Panasonic (formerly Sunx) and standard 2.2mm OD fiber terminated fiber cables
Pushbutton teach and programming
Many programmable features including time delay
Requires Panasonic (formerly Sunx) CN73 hook-up cable (Available separately, see recommended products)
4.152.000 ₫
Thông tin bổ sung
| Thương hiệu | Panasonic |
|---|
