Bộ khuếch đại sợi quang Panasonic FX-311G

Name: Bộ khuếch đại sợi quang Panasonic FX-311G
Brand: Panasonic
SKU: FX-311G
Availability: InStock

Panasonic (formerly Sunx) Manual Adjustable Green LED Fiber Optic Amplifier12-turn finger adjustable potentiometer provides max sensitivityGreen LED light source12 to 24 VDC inputNPN outputWorks with all 2.2 mm OD plastic fiber cablesRequires Panasonic CN-73 hook-up cable which is sold separately. See recommended products below.

4.293.000 ₫

Mã sản phẩm: FX-311G Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FX-311
Remove Discontinued
Currrent Model
Setting Type
Manual Adjustment
Setting Type Detail
Potentiometer 12-turn
Display Type
LED Indicators
Display Detail
Output & stability
Features
12-turn pot enables detection of very fine differences. Convenient built-in “assist function” indicates the optimum sensitivity position by flashing rapidly when optimum sensitivity is reached
Light Source
Green LED
Amplifier Type
Interconnect Type – Master/Slave
Output Type
NPN
Output Details
1 each NPN
Connection Type
Cable w/conn
Connection Details
Use CN-70 Series Connector/cable
Supply Voltage
DC
Voltage Details
12 to 24VDC
Fastest Respose Time
150µs
Time Delay Option
10 or 40 ms Off Delay
Counter Option
No
Remote Input Feature
No
Cross Talk Prevention
Up to 4 units
Item Weight
0.00 lbs per EA
