Bộ khuếch đại sợi quang Panasonic FX-301BP

Name: Bộ khuếch đại sợi quang Panasonic FX-301BP
Brand: Panasonic
SKU: FX-301BP
Availability: InStock

Panasonic (formerly Sunx) Digital Fiber Optic Amplifier

Blue LED light source
PNP output
12 to 24 VDC
DIN rail mount
Accepts all Panasonic and standard 2.2 mm OD fiber terminated fiber cables
Push-button teach and programmingMany programmable features including time delay
Requires Panasonic CN-73-C_ quick connection cable (sold separately – see recommended products)

5.366.000 ₫

Mã sản phẩm: FX-301BP Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FX-300
Remove Discontinued
Currrent Model
Setting Type
PB Teaching
Setting Type Detail
PB Teach with fine adjust
Display Type
Digital LED Display
Display Detail
4-digit Red LED display, LED Status Indicators
Features
Four levels of LED light levels can be selected to prevent saturation. Window comparator and differential sensing modes are simplified for easy use. Intuitive LED display confirm basic operations.
Light Source
Blue LED
Amplifier Type
Interconnect Type – Master/Slave
Output Type
PNP
Output Details
1 each PNP
Connection Type
Cable w/conn
Connection Details
Use CN-70 Series Connector/cable
Supply Voltage
DC
Voltage Details
12 to 24VDC
Fastest Respose Time
60µs
Time Delay Option
Multifunction
Counter Option
No
Remote Input Feature
No
Cross Talk Prevention
Up to 4 units
Item Weight
0.00 lbs per EA
