Bộ khuếch đại sợi quang Panasonic FX-102-Z

Name: Bộ khuếch đại sợi quang Panasonic FX-102-Z
Brand: Panasonic
SKU: FX-102-Z
Availability: InStock

Panasonic (formerly Sunx) Digital Fiber Optic AmplifierLong sensing range type12 to 24 VDCNPN outputDIN rail mountRed LED light sourceAccepts all Panasonic (formerly Sunx) and standard 2.2 mm OD fiber terminated fiber cablesPush-button or remote input teachMany programmable features including time delayM8 4 pin quick disconnect (mating cable sold separately)Note: Power cable not supplied and is sold separately. Requires CN-24A type cables. See related products.

2.743.000 ₫

SKU: FX-102-Z Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FX-100
Remove Discontinued
Currrent Model
Setting Type
PB Teaching
Setting Type Detail
PB Teach with fine adjust
Display Type
Digital LED Display
Display Detail
Dual 4-digit Red/Grn display,LED Status Indicators
Features
Long distance sensing amp. Simply press ON-target is present, OFF-no target – teaching is complete. If the settings are accidentally changed, imputing the code will restore the default settings
Light Source
Red LED
Amplifier Type
Stand Alone
Output Type
NPN
Output Details
1 each NPN
Connection Type
Quick Disconnect
Connection Details
M8 4P QD
Supply Voltage
DC
Voltage Details
12 to 24 VDC
Fastest Respose Time
2.5ms
Time Delay Option
Multifunction
Counter Option
No
Remote Input Feature
Yes
Cross Talk Prevention
Up to 4 units
Protection Rating
Not listed
Includes
FC-FX-1 Protection Cover Unit
Item Weight
0.08 lbs per EA
