Cảm biến sợi quang Panasonic FT-Z30E

Name: Cảm biến sợi quang Panasonic FT-Z30E
Brand: Panasonic
SKU: FT-Z30E
Availability: InStock

Panasonic (formerly Sunx) Thrubeam Fiber Optic Cable Flat with Compact HeadRectangular headOnly W3 x H12 x D8Side sensing type2 meter high-flex cuttable fiber has R2 bend radius

2.284.000 ₫

Mã sản phẩm: FT-Z30E Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thin Rectangular
Sensing Mode
Thrubeam
Key Attributes
Side Sensing
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
Square/Rectangular
Mounting Dimension
3mm x 8mm x 12mm
Fiber Cable Feature
Super thin body and rectangular shape can be installed in very narrow locations. Two screw mounting.
Fiber Cable Bend Radius
R2 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 0.75mm
Temperature Rating
-40 to +60° C
Includes
FX-AT5 grey attachment w/tips for Ø1.0mm cuttable fibers, and cutter
