Cảm biến sợi quang Panasonic FT-Z20HBW

Name: Cảm biến sợi quang Panasonic FT-Z20HBW
Brand: Panasonic
SKU: FT-Z20HBW
Availability: InStock

Panasonic (formerly Sunx) Flat Style Rectangular Thrubeam Fiber Optic CableW2 x H10 x D10 with mounting bossEnd or side sense – Equipped with a fiber guide feature. This enables the sensor be mounted either end or side sensing1 meter free cut cable with R1 bending radius

2.697.000 ₫

Mã sản phẩm: FT-Z20HBW Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thin Rectangular
Sensing Mode
Thrubeam
Key Attributes
Axial Sensing
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
Square/Rectangular
Mounting Dimension
2mm x 10mm x 10mm
Fiber Cable Feature
Super thin body and rectangular shape can be installed in very narrow locations. Sensing body features bottom boss for 1-point mounting installation.
Fiber Cable Bend Radius
R1 Tight Bend
Cuttable / Non-Cuttable
Cuttable
Fiber Length
1 meter
Fiber Core
Ø 0.5mm
Temperature Rating
-40 to +60° C
Includes
FX-AT4 black attachment w/tips for Ø1.0mm cuttable fibers, fiber cutter
