Cảm biến sợi quang Panasonic FT-H35-M2

Name: Cảm biến sợi quang Panasonic FT-H35-M2
Brand: Panasonic
SKU: FT-H35-M2
Availability: InStock

Panasonic (formerly Sunx) High Temperature Thrubeam Fiber Optic CableTemperature rating of -60° to 350°C with R25 mm bending radiusM4 threaded sensing head with M2.6 × 0.45 threaded tip for adding expansion lens1.2 mm fiber core2m long non-cuttable stainless steel flex-tube fiber cable length

FT-H35-M2 Dimensional Drawing

9.062.000 ₫

Mã sản phẩm: FT-H35-M2 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Heat-resistant
Sensing Mode
Thrubeam
Key Attributes
Axial Sensing
Lens Compatible
Add-On Lens Compatible
Mounting Body Style
M4
Mounting Dimension
M4 x 30mm
Fiber Cable Feature
Features wide temperature range for use in severe temperture enviroments SUS Sheath Provides Fiber Cable Protection Use add-on lens for increasing sensing distance: FX-LE1, FX-LE2, and Side-view type
Fiber Cable Bend Radius
R25
Cuttable / Non-Cuttable
Non-Cuttable w/ SUS Jacket
Fiber Length
2 meter
Fiber Core
Ø 1.2mm
Temperature Rating
-60 to +350° C
Includes
Mounting hardware
Item Weight
0.29 lbs per EA
