Cảm biến sợi quang Panasonic FT-H30-M1V-S

Name: Cảm biến sợi quang Panasonic FT-H30-M1V-S
Brand: Panasonic
SKU: FT-H30-M1V-S
Availability: InStock

Panasonic (formerly Sunx) Thrubeam Vacuum Fiber Kit
Sold as a set and includes:

Vacuum fiber cables (FT-H30-M1V)Photo-terminals (FV-BR1)Atmospheric side fiber (FT-J8)

FT-H30-M1V-S Dimensional Drawing

26.470.000 ₫

Mã sản phẩm: FT-H30-M1V-S Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Series
FT/FD/FR
Key Characteristics
Vacuum-resistant
Sensing Mode
Thrubeam
Key Attributes
Axial Sensing
Lens Compatible
Add-On Lens Compatible
Mounting Body Style
M4
Mounting Dimension
M4 x 30mm
Fiber Cable Feature
Vacuum-resistant set includes vacuum side and atmospheric side fibers with FV-BR1 photo-terminals. Works with add-on lens FV-LE1 and FV-SV1
Fiber Cable Bend Radius
R18
Cuttable / Non-Cuttable
Non-Cuttable
Fiber Length
1 meter
Temperature Rating
-30 to +300° C
Includes
Attachment for photo-terminal connection
Item Weight
0.29 lbs per EA
