Cảm biến sợi quang Panasonic FT-H20-VJ80-S

Name: Cảm biến sợi quang Panasonic FT-H20-VJ80-S
Brand: Panasonic
SKU: FT-H20-VJ80-S
Availability: InStock

Panasonic (formerly Sunx) heat resistant side view fiber joint cable kit – 2 pieces total
Includes 1 set of each:

800 mm heat resistant fiber that is rated to 200° C
FT-42 standard temperature fiber with connector, 2 m free-cut standard fiber cable, temp rated to 80° C

Note: Amplifier sold separately

FT-H20-VJ80-S Dimensional Drawing

8.943.000 ₫

SKU: FT-H20-VJ80-S Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Heat-resistant
Sensing Mode
Thrubeam
Key Attributes
Side-View
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
Ø 4.0mm
Mounting Dimension
Ø 4.0mm x 24mm
Fiber Cable Feature
Heat-resistant joint fiber set includes fibers for high-temp side and fiber for ordinary side. SUS Sheath Provides Fiber Cable Protection
Fiber Cable Bend Radius
R4 High-flex
Cuttable / Non-Cuttable
Cuttable w/SUS Jacket
Fiber Length
2.8 meter
Fiber Core
Ø 1.0mm
Temperature Rating
-60 to +200° C
Includes
FT-42, FX-AT3 transclucent orange attachment for Ø2.2mm cuttable fibers, fiber cutter
Item Weight
0.31 lbs per EA
