Cảm biến sợi quang Panasonic FT-AL05

Name: Cảm biến sợi quang Panasonic FT-AL05
Brand: Panasonic
SKU: FT-AL05
Availability: InStock

Panasonic (formerly Sunx) Array Type Thrubeam Fiber Optic CableProvides 5.5 mm wide arrayPlastic housing860 mm sensing distance when using FX-500 series amplifier on STD mode2 meter high-flex free cut cable with 2 mm bending radius

3.840.000 ₫

SKU: FT-AL05 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Wide Beam Array
Sensing Mode
Thrubeam
Key Attributes
Array Beam
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
Square/Rectangular
Mounting Dimension
5mm x 15mm x 15mm
Fiber Cable Feature
Features compact 5.5mm wide beam array.
Fiber Cable Bend Radius
R2 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 0.25mm x 16
Temperature Rating
-55 to +80° C
Includes
FX-AT3 transclucent orange attachment for Ø2.2mm cuttable fibers, fiber cutter
