Cảm biến sợi quang Panasonic FT-43

Name: Cảm biến sợi quang Panasonic FT-43
Brand: Panasonic
SKU: FT-43
Availability: InStock

Panasonic (formerly Sunx) Thru Beam Fiber optic Cable M4 threaded Sensing Head 15mm Long
1.5mm core diameter fiber allowing increased Excess Gain
1.4 Meter Sensing Distance with FX-500 Series Amplifier at STD Mode2 Meter Free Cut Cable with 2mm Bending Radius

1.299.000 ₫

Mã sản phẩm: FT-43 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Thrubeam
Key Attributes
Axial Sensing
Lens Compatible
Add-On Lens Compatible
Mounting Body Style
M4
Mounting Dimension
M4 x 15mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°Use add-on lens for increasing sensing distance: FX-LE1, FX-LE2, and Side-view type FX-SV1
Fiber Cable Bend Radius
R4 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 1.5mm
Temperature Rating
-55 to +80° C
Includes
FX-AT3 transclucent orange attachment for Ø2.2mm cuttable fibers, fiber cutter
