Cảm biến sợi quang Panasonic FD-Z40W

Item Specifications

• Series
  FT/FD/FR
• Key Characteristics
  Thin Rectangular
• Sensing Mode
  Diffuse
• Key Attributes
  Front Sensing
• Lens Compatible
  Not Compatible With Add-On Lens
• Mounting Body Style
  Square/Rectangular
• Mounting Dimension
  14mm x 7mm x 3.5mm
• Fiber Cable Feature
  Super thin body and rectangular shape can be installed in very narrow locations. Sensing body features bottom boss for 1-point mounting installation.
• Fiber Cable Bend Radius
  R1 Tight Bend
• Cuttable / Non-Cuttable
  Cuttable
• Fiber Length
  2 meter
• Fiber Core
  Ø 1.0mm
• Temperature Rating
  -40 to +60° C
• Includes
  FX-AT5 grey attachment w/tips for Ø1.0mm cuttable fibers, and cutter
• Item Weight
  0.10 lbs per EA
