Cảm biến sợi quang Panasonic FD-L22A

Panasonic (formerly Sunx) Convergent Fiber Optic Cable for Glass Substrate DetectionUltra-slim design is only 3.8 mm thickFeatures convergent reflective design for alignment of LCD glassSensing distance of 0 to 28 mm2 meter high-flex free cut fiber optic cable with 2mm bending radius

FD-L22A Dimensional Drawing

4.222.000 ₫

Báo giá
SKU: FD-L22A Danh mục: Thương hiệu:
Dòng sản phẩmFT/FD/FR
Đặc tính chínhLimited Distance
Chế độ phát hiệnConvergent
Đặc tính kỹ thuậtFront Sensing
Ống kính tương thíchNot Compatible With Add-On Lens
Kiểu thân lắp đặtSquare/Rectangular
Kích thước lắp đặt17mm x 29mm x 3.8mm
Đặc điểm cáp quangSensing Distance is limited to a specific range and is not easily affected by the background. Works Well for Glass Substrate Detection and Alignment Applications.
Bán kính uốn cáp quangR2 High-flex
Có thể cắt/Không thể cắtCuttable
Chiều dài sợi quang2 meter
Lõi sợi quangØ 2.5mm
Nhiệt độ định mức0 to +70° C
Phụ kiện đi kèmFX-AT5 grey attachment w/tips for Ø1.0mm cuttable fibers, and cutter

Thông tin bổ sung

Thương hiệu

Panasonic
