Cảm biến sợi quang Panasonic FD-EG31

Name: Cảm biến sợi quang Panasonic FD-EG31
Brand: Panasonic
SKU: FD-EG31
Availability: InStock

Panasonic (formerly Sunx) Diffuse Reflective Fiber Optic Cable with Coaxial Optics
Lens Mountable FX-MR3, FX-MR6
M3 Threaded Barrel 16mm long
1 Meter non-cuttable Fiber cable with 4mm bending radius

2.721.000 ₫

Mã sản phẩm: FD-EG31 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse Coaxial
Key Attributes
Axial Sensing
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
M3
Mounting Dimension
M3 x 16mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±5°For High Precision Beam Spot use the following add-on lens: FX-MR6 for Ø0.1mm at 7mm distance, FX-MR3 for Ø0.15mm at 7mm distance
Fiber Cable Bend Radius
R4 High-flex
Cuttable / Non-Cuttable
Non-Cuttable
Fiber Length
1 meter
Fiber Core
Ø 0.125mm x 1 / Ø 0.125mm x 6
Temperature Rating
-20 to +60° C
Includes
Designed to fit FX110/300/500 amplifiers
