Cảm biến sợi quang Panasonic FD-EG30S

Name: Cảm biến sợi quang Panasonic FD-EG30S
Brand: Panasonic
SKU: FD-EG30S
Availability: InStock

Panasonic (formerly Sunx) Diffuse Reflective Fiber Optic CableCoaxial optics3mm threaded barrel15mm long, 0.8mm diameter non-bendable sleeve1 meter non-cuttable fiber cable with 4mm bending radius
FD-EG30S Dimensional Drawing

1.860.000 ₫

Mã sản phẩm: FD-EG30S Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse Coaxial
Key Attributes
Sleeve Non-Bendable
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
M3
Mounting Dimension
M3 x 15mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±5°Featues SUS body, nuts, locking washers. Sleeve cannot be bent to shape.
Fiber Cable Bend Radius
R4 High-flex
Cuttable / Non-Cuttable
Non-Cuttable
Fiber Length
1 meter
Fiber Core
Ø 0.25mm x 1 / Ø 0.125mm x 9
Temperature Rating
-40 to +70° C
Includes
Designed to fit FX110/300/500 amplifiers
