Cảm biến sợi quang Panasonic FD-61S

Name: Cảm biến sợi quang Panasonic FD-61S
Brand: Panasonic
SKU: FD-61S
Availability: InStock

Panasonic (formerly Sunx) Diffuse Fiber Cable40mm long – 1.48mm diameter sleeveM4 threaded barrel – 12mm long2 meter free-cut high-flex cable with 2mm bending radius

1.155.000 ₫

Mã sản phẩm: FD-61S Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse
Key Attributes
Sleeve Bendable
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
M6
Mounting Dimension
M6 x 15mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°. For bending sleeve use FB-1 bending tool
Fiber Cable Bend Radius
R4 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 1.0mm
Temperature Rating
-55 to +80° C
Includes
FX-AT3 transclucent orange attachment for Ø2.2mm cuttable fibers, fiber cutter
