Cảm biến sợi quang Panasonic FD-42GW

Name: Cảm biến sợi quang Panasonic FD-42GW
Brand: Panasonic
SKU: FD-42GW
Availability: InStock

Panasonic (formerly Sunx) Tight Bend Diffuse Fiber Cable with Coaxial Optics M4 threaded barrel 20mm long plus 5mm M3 threaded tip Can be used with focusing lenses2 meter free-cut cable with 1mm bending radius

2.028.000 ₫

Mã sản phẩm: FD-42GW Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse Coaxial
Key Attributes
Axial Sensing
Lens Compatible
Add-On Lens Compatible
Mounting Body Style
M4
Mounting Dimension
M4 x 25mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°For High Precision Beam Spot use the following add-on lens: FX-MR2 for adjustable Ø 0.7mm to Ø 2.0 spot at 18mm to 43mm distance,
Fiber Cable Bend Radius
R1 Tight Bend
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 0.25mm x 9 / Ø 0.5mm x 1
Temperature Rating
-40 to +60° C
Includes
FX-AT6 black/grey attachment w/tips for Ø2.2 / Ø1.0mm cuttable fibers, and fiber cutter
