Cảm biến sợi quang Panasonic FD-41

Name: Cảm biến sợi quang Panasonic FD-41
Brand: Panasonic
SKU: FD-41
Availability: InStock

Panasonic (formerly Sunx) Diffuse Fiber Cable with Side by Side OpticsM4 threaded barrel 14mm long2 meter free-cut cable with 2mm bending radius

789.000 ₫

Mã sản phẩm: FD-41 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse
Key Attributes
Axial Sensing
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
M4
Mounting Dimension
M4 x 14mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°
Fiber Cable Bend Radius
R2 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 0.5mm
Temperature Rating
-55 to +80° C
Includes
FX-AT4 black attachment w/tips for Ø1.0mm cuttable fibers, fiber cutter
Item Weight
0.15 lbs per EA
