Cảm biến sợi quang Panasonic FD-31

Name: Cảm biến sợi quang Panasonic FD-31
Brand: Panasonic
SKU: FD-31
Availability: InStock

Panasonic (formerly Sunx) diffuse fiber cable for side by side optics
BARREL: M3 threaded – 12mm longCABLE: 2 meter long free-cut cable – ø1 mmBEND RADIUS: R2 – 2mm bending radius

954.000 ₫

Mã sản phẩm: FD-31 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
FT/FD/FR
Key Characteristics
Thread Mount
Sensing Mode
Diffuse
Key Attributes
Axial Sensing
Lens Compatible
Not Compatible With Add-On Lens
Mounting Body Style
M3
Mounting Dimension
M3 x 15mm
Fiber Cable Feature
Featues SUS body, nuts, locking washers. Beam Axis deviation within ±3°
Fiber Cable Bend Radius
R2 High-flex
Cuttable / Non-Cuttable
Cuttable
Fiber Length
2 meter
Fiber Core
Ø 0.5mm
Temperature Rating
-55 to +80° C
Includes
FX-AT4 black attachment w/tips for Ø1.0mm cuttable fibers, fiber cutter
Item Weight
0.15 lbs per EA
