Cảm biến quang Panasonic EX-29A

Name: Cảm biến quang Panasonic EX-29A
Brand: Panasonic
SKU: EX-29A
Availability: InStock

Panasonic (formerly Sunx) Ultra Compact Retro-Reflective Photoelectric Sensor12 to 24 VDCSide Sensing TypeOnly 8.2mm thickRed LED light source with sensing range of 30 to 200mmNPN output Light-On mode2 meter connection cable

2.697.000 ₫

SKU: EX-29A Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
EX-20
Sensor Body Type
Miniature
Sensor Body Feature
Side sense 8.2mm thick, H22 x W12.3
Sensing Mode
Retro-reflective
Sensing Mode Details
Non-polarized includes RF-200 reflector
Sensor Features
Ø15.0mm Min Detectable Object, 0.5 Repeatability, 0.5ms Response, 1-Turn Potentiometer Adjustment
Light Source
Red LED
Supply Voltage Details
12 to 24VDC
Sensing Range
30mm to 200mm
Output
NPN
Output Details
1 each NPN
Timer
No
Output Mode
Light-On
Construction
Polyethylene terephthalate enclosure, Polyalylate lens
Temperature
-20º to +55º C
IEC/Nema Rating Details
IP67
Connection Detail
Cable 2m
Item Weight
0.05 lbs per EA
