Cảm biến quang Panasonic EX-19EA-PN

Incredibly Small Photoelectric Sensor with Built-In Amplifier
Smallest Body – Just 4.5 mm ThickWith incredibly small dimensions, the EX-10 series can be mounted in very small spaces. 10mm W x 20mm H x 4.5mm D(thru-beam, side sensing type)
Key Features:

Panasonic (formerly Sunx) Ultra Slim Miniature Photoelectric Sensor
12 to 24 VDC
Side Sensing Type. Only 4.5 mm thick
Thrubeam sensing with Red LED light source
Sensing range 1 meter
PNP output Light-On mode
2 meter connection cable
EX-19EA-PN includes the following 2 part numbers: EX-19EAP (Projector Portion) and EX-19EA-PND (Detector Portion)

Flexible Mounting:The diffuse reflective type sensor is front sensing and is so thin that it can be mounted nearly anywhere. The thru-beam type is available as front sensing type, as well as, side sensing type, allowing flexible mounting making it a flexible sensing solution.
Uses Up To 65% Less Electricity style=”margin-left: 10px; margin-bottom: 10px; float: right;” src=”../image/descriptions/panasonic_ex-10_less_energy_usage.jpg# alt=”Up to 65% Less Energy Usage” width=”200″ height=”160″>The EX-10 series achieves reductions in power consumption of up to 65 % and are environmentally friendly. Effective in products produced since October 2010.

Wide Variety of Narrow-Beam Types. Light Diffusion is Approx. Half of Standard Types.
Less Interference With No Slit, Narrow Pitch Can Be SetThe pitch of installation is half of conventional models, so that the close-installation is possible. No cost to purchase or install a slit.
Sense Small Objects Less Than ø0.5mm With No SlitThe EX-10 series is applicable of sensing minute objects.
Long Sensing Range of 1m (3.281′) with a Narrow Beam

Performance
High Speed Response Time: 0.5msThe EX-10 Series is great for detecting small and highspeed traveling objects.
Background SuppressionEven a specular background separated by 100 mm 3.937 in, or more, is not detected. Note: the background should be directly opposite. A spherical or curved background may be detected.
Reliably Detects Black ObjectsThe EX-10 series can reliably detect dark color objects due to it being a convergent reflective type sensor.

Environmental Resistance
Improved Protection from Extraneous LightThe EX-10 series is significantly improved against inverter light and other extraneous light due to the incorporated inverter countermeasure circuit. * Effective in products produced since October 2010.
Waterproof IP67The sensor can be hosed down because of its IP67 construction and the non-corrosive stainless steel mounting bracket. Note: However, take care that if it is exposed to water splashes during operation, it may detect a water drop itself.
Bending DurabilityFlexible cable type EX-?-R is available. It is most suitable for moving parts, such as robot arm, etc.

Mounting / Size – Mountable with M3 Screws
Non-corrosive stainless steel type sensor mounting bracket is also available.
