| Dòng sản phẩm | EX-10 |
| Kiểu thân cảm biến | Miniature Ultra-thin |
| Đặc điểm thân cảm biến | Front sense 3.5mm thick, H19 x W10 |
| Chế độ phát hiện | Thrubeam |
| Chi tiết chế độ phát hiện | ø1.0mm Min Detectable Object |
| Đặc điểm cảm biến | Repeat accuracy of 0.05mm, high speed response of 0.5ms |
| Nguồn sáng | LED đỏ |
| Thông số nguồn cấp | 12 to 24VDC |
| Phạm vi phát hiện | 150mm |
| Ngõ ra | NPN |
| Chi tiết ngõ ra | 1 each NPN |
| Chức năng Timer | Không |
| Chế độ ngõ ra | Light-On/Dark-On selectable |
| Cấu tạo | Polyethylene terephthalate enclosure, Polyalylate lens, switching enclosure |
| Nhiệt độ | -20º to +55º C |
| Cấp bảo vệ IEC/NEMA | IP67 |
| Chi tiết kết nối | Cable 2m |
| Khối lượng | 0.13 lbs per EA |
Cảm biến quang Panasonic EX-15
Incredibly Small Photoelectric Sensor with Built-In Amplifier
Smallest Body – Just 3.5 mm (.138”) ThickWith incredibly small dimensions, the EX-10 series can be mounted in very small spaces. 10mm W x 14.5mm H x 3.5mm D.394” W x .571” H x .138” D (thru-beam, front sensing type)
Key Features:
Panasonic (formerly Sunx) Ultra Slim Miniature Photoelectric Sensor
12 to 24 VDC
Front Sensing Type. Only 3.5mm thick
Thrubeam sensing with Red LED light source
Sensing range 150mm
NPN output with LO/DO switch 500mm from sensing head
2 meter connection cable
4.152.000 ₫
Thông tin bổ sung
| Thương hiệu | Panasonic |
|---|
