Cảm biến quang Panasonic CX-412B-C05

Name: Cảm biến quang Panasonic CX-412B-C05
Brand: Panasonic
SKU: CX-412B-C05
Availability: InStock

Effective the end of September, 2021 this sensor will be discontinued. Suggested replacement: CX-412 with 1m cable and selectable LO/DO mode.Panasonic (formerly Sunx) Compact Thru Beam Photoelectric Sensor 15 Meter Sensing Distance Infrared LED Light Source12 to 24 VDC NPN Dark-On Output Cabled Type 0.5 Meter IP67

1.347.000 ₫

Mã sản phẩm: CX-412B-C05 Danh mục: Cảm biến Panasonic Thương hiệu: Panasonic

Mô tả
Thông tin bổ sung

Item Specifications

Series
CX-400
Sensor Body Type
Compact Rectangular Plastic
Sensor Body Feature
H31 x W11 x D20, tough acrylic lens
Sensing Mode
Thrubeam
Sensing Mode Details
Long sensing range strong IR beam
Sensor Features
Potentiometer adjustment, ø12mm minimum sensing target – opaque, 0.5mm repeatability
Light Source
Infrared LED
Supply Voltage Details
12 to 24VDC
Sensing Range
15 meter
Output
NPN
Output Details
1 each NPN
Timer
No
Output Mode
Dark-On
Construction
PBT enclosure, Acrylic lens
Temperature
-25º to +55º C
IEC/Nema Rating Details
IP67
Connection Detail
Cable 0.5m
Item Weight
1.00 lbs per EA
