| Thông số | Giá trị |
|---|---|
| Model | KV-RC8BXT |
| Intermittent vibration frequency (5 to 9Hz) | Half amplitude: 3.5 mm |
| Intermittent vibration frequency (9 to 150Hz) | Acceleration: 9.8 m/s² |
| Continuous vibration frequency (5 to 9Hz) | Half amplitude: 1.75 mm |
| Continuous vibration frequency (9 to 150Hz) | Acceleration: 4.9 m/s² |
| Current consumption | At 11.4 V: 120 mA or less, at 26.4 V: 60 mA or less |
| Power voltage | Rated voltage: 12 to 24 VDC, supply voltage range: 11.4 to 26.4 VDC |
| Operating ambient temperature | 0 to +60°C (no freezing) |
| Operating ambient humidity | 10 to 95%RH (no condensation) |
| Ambient temperature for storage | -20 to +75°C |
| Overvoltage category | II |
| Pollution degree | 2 |
| Storage relative humidity | 10 to 95%RH (no condensation) |
| CE marking | EMI: EN55011 Class A, EMS: EN61131-2, low voltage directive: EN61131-2 |
| Operating environment | Minimal amount of dust and corrosive gas present |
| Altitude | 2000m or less |
| FCC | FCC Part15B class A |
| UL | UL : UL508CSA : CAN／CSA22, 2 No.14 |
| ICES | ICES-003 Issue4 |
| Noise immunity | 1,500 Vp-p or more, pulse width: 1 µs, 50 ns (by way of a noise simulator), conforms to IEC standards (IEC 61131-2) |
| Withstand voltage | 1,500 VAC for 1 minute (between the power supply terminal and the communication terminal, between the power supply terminal and the I/O terminals, and between all the external terminals and the case) |
| Enclosure rating | IP2X |
| Insulation resistance | 100 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminal) |
| CC-Link specifications | Supported version: 1.10, number of occupied stations: 1, station type: remote I/O station |
| Input maximum rating | DC26.4V |
| Input voltage | DC24V approx 5.3mA |
| Minimum ON voltage | 19V |
| Maximum OFF voltage | 2.0mA |
| Input impedance | 4.3 kΩ |
| Insulation system | Photocoupler isolation |
| Input time constant | 0.2 ms, 1.5 ms, 10 ms |
| Output | Transistor output (sink type) |
| Operating load voltage range | DC10.2 to 26.4V |
| Output unit external power supply | DC12/24V |
| Output load current | 0.5 A/output, 5 A/unit (total) |
| Leaked current at OFF | 0.1mA or less |
| Maximum decreased voltage at ON | 0.3 V (typ.) or less, 0.6 V (max.) or less |
| Output response time (OFF → ON) | 0.1ms or less |
| Output response time (ON → OFF) | 1.0ms or less |
| Insulation | Photocoupler isolation |
| Weight | approx 250g |
CC-Link Module Keyence KV-RC8BXT (8 in/ 8 out transistor)
SKU: KV-RC8BXT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Báo giá
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
