CC-link Module Keyence KV-RC16BXT (16 in/ 16 out transistor)

Thông số	Giá trị
Model	KV-RC16BXT
Intermittent vibration Frequency: 5 to 9Hz	Half amplitude: 3.5 mm
Intermittent vibration Frequency: 9 to 150Hz	Acceleration: 9.8 m/s²
Continuous Vibration Frequency: 5 to 9Hz	Half amplitude: 1.75 mm
Continuous Vibration Frequency: 9 to 150Hz	Acceleration: 4.9 m/s²
Current consumption	At 11.4 V: 150 mA or less, at 26.4 V: 80 mA or less
Power voltage	Rated voltage: 12 to 24 VDC, supply voltage range: 11.4 to 26.4 VDC
Operating ambient temperature	0 to +60°C (no freezing)
Operating ambient humidity	10 to 95%RH (no condensation)
Ambient temperature for storage	-20 to +75°C
Overvoltage category	II
Pollution degree	2
Storage relative humidity	10 to 95%RH (no condensation)
CE marking	EMI: EN55011 Class A, EMS: EN61131-2, low voltage directive: EN61131-2
Operating environment	Minimal amount of dust and corrosive gas present
Altitude	2000m or less
FCC	FCC Part15B class A
UL	UL :UL508CSA :CAN/CSA22,2 No.14
ICES	ICES-003 Issue4
Noise immunity	1,500 Vp-p or more, pulse width: 1 µs, 50 ns (by way of a noise simulator), conforms to IEC standards (IEC 61131-2)
Withstand voltage	1,500 VAC for 1 minute (between the power supply terminal and the communication terminal, between the power supply terminal and the I/O terminals, and between all the external terminals and the case)
Enclosure rating	IP2X
Insulation resistance	100 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminal)
CC-Link specifications	Supported version: 1.10, number of occupied stations: 1, station type: remote I/O station
Input maximum rating	DC26.4V
Input voltage	DC24V approx 5.3mA
Minimum ON voltage	19V
Maximum OFF voltage	2.0mA
Input impedance	4.3 kΩ
Insulation system	Photocoupler isolation
Input time constant (switching method)	· 0.2 ms · 1.5 ms · 10 ms
Output	Transistor output (sink type)
Operating load voltage range	DC10.2 to 26.4V
Output unit external power supply	DC12/24V
Output load current	0.5 A/output, 5 A/unit (total)
Leaked current at OFF	0.1mA or less
Maximum decreased voltage at ON	0.3 V (typ.) or less, 0.6 V (max.) or less
Output response time (OFF → ON)	0.1ms or less
Output response time (ON → OFF)	1.0ms or less
Insulation	Photocoupler isolation
Weight	approx 250g
Notes	For only the KV-RC8BXT, this is 4 A/unit (total).
