| Thông số | Giá trị |
|---|---|
| Model | KV-RC16BT |
| Intermittent vibration | Frequency: 5 to 9Hz, Half amplitude: 3.5 mm* |
| Intermittent vibration | Frequency: 9 to 150Hz, Acceleration: 9.8 m/s²* |
| Continuous vibration | Frequency: 5 to 9Hz, Half amplitude: 1.75 mm* |
| Continuous vibration | Frequency: 9 to 150Hz, Acceleration: 4.9 m/s²* |
| Current consumption | At 11.4 V: 120 mA or less, at 26.4 V: 60 mA or less |
| Power voltage | Rated voltage: 12 to 24 VDC, supply voltage range: 11.4 to 26.4 VDC |
| Operating ambient temperature | 0 to +60°C (no freezing) |
| Operating ambient humidity | 10 to 95%RH (no condensation) |
| Ambient temperature for storage | -20 to +75°C |
| Approved standards | Overvoltage category: II, Pollution degree: 2 |
| Storage relative humidity | 10 to 95%RH (no condensation) |
| CE marking | EMI: EN55011 Class A, EMS: EN61131-2, low voltage directive: EN61131-2* |
| Operating environment | Minimal amount of dust and corrosive gas present |
| Altitude | 2000m or less |
| FCC | FCC Part 15B class A |
| UL | UL: UL508, CSA: CAN/CSA22, No.14 |
| ICES | ICES-003 Issue 4 |
| Noise immunity | 1,500 Vp-p or more, pulse width: 1 µs, 50 ns, conforms to IEC standards (IEC 61131-2) |
| Withstand voltage | 1,500 VAC for 1 minute |
| Enclosure rating | IP2X |
| Insulation resistance | 100 MΩ or more |
| CC-Link specifications | Supported version: 1.10, number of occupied stations: 1, station type: remote I/O station |
| Output specifications | Transistor output (sink type) |
| Operating load voltage range | DC10.2 to 26.4V |
| Rated load voltage | DC12/24V |
| Output load current | 0.5 A/output, 5 A/unit (total)* |
| Leaked current at OFF | 0.1mA or less |
| Maximum decreased voltage at ON | 0.3 V (typ.) or less, 0.6 V (max.) or less |
| Output response time (OFF -> ON) | 0.1ms or less |
| Output response time (ON -> OFF) | 1.0ms or less |
| Insulation | Photocoupler isolation |
| Weight | Approx. 250g |
| Notes | *1 Conforms to JIS B 3502 IEC61131-2, *2 Only models KV-RC16BR and KV-RC8BXR support the low voltage directive. *3 For KV-RC8BXT, this is 4 A/unit (total). |
CC-link Module Keyence KV-RC16BT (16 ngõ ra relay)
SKU: KV-RC16BT
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
