| Thông số | Giá trị |
|---|---|
| Model | KV-RC16BR |
| Vibration Resistance (Intermittent Vibration, 5 to 9Hz) | Half amplitude: 3.5 mm*1 |
| Vibration Resistance (Intermittent Vibration, 9 to 150Hz) | Acceleration: 9.8 m/s2*1 |
| Vibration Resistance (Continuous Vibration, 5 to 9Hz) | Half amplitude: 1.75 mm*1 |
| Vibration Resistance (Continuous Vibration, 9 to 150Hz) | Acceleration: 4.9 m/s2*1 |
| Current Consumption (at 11.4V) | 390 mA or less |
| Current Consumption (at 26.4V) | 150 mA or less |
| Power Voltage | Rated voltage: 12 to 24 VDC, supply voltage range: 11.4 to 26.4 VDC |
| Operating Ambient Temperature | 0 to +60°C (no freezing) |
| Operating Ambient Humidity | 10 to 95%RH (no condensation) |
| Storage Ambient Temperature | -20 to +75°C |
| Overvoltage Category | II |
| Pollution Degree | 2 |
| Storage Relative Humidity | 10 to 95%RH (no condensation) |
| CE Marking | EMI: EN55011 Class A, EMS: EN61131-2, Low Voltage Directive: EN61131-2*2 |
| Operating Environment | Minimal amount of dust and corrosive gas present |
| Altitude | 2000m or less |
| FCC | FCC Part15B class A |
| UL | UL : UL508CSA : CAN／CSA22、2 No.14 |
| ICES | ICES-003 Issue4 |
| Noise Immunity | 1,500 Vp-p or more, pulse width: 1 µs, 50 ns (by way of a noise simulator), conforms to IEC standards (IEC 61131-2) |
| Withstand Voltage | 1,500 VAC for 1 minute (between the power supply terminal and the communication terminal, between the power supply terminal and the I/O terminals, and between all the external terminals and the case) |
| Enclosure Rating | IP2X |
| Insulation Resistance | 100 MΩ or more (tested with a 500 VDC megger, between the power supply terminal and the I/O terminal) |
| CC-Link Specifications | Supported version: 1.10, Number of occupied stations: 1, Station type: Remote I/O station |
| Rated Voltage | AC240V/DC24V |
| Rated Output Current | 240 VAC, 24 VDC, 2 A/output, 4 A/common |
| ON Resistance | 50 mΩ or less |
| ON Delay Time | 10ms or less |
| Insulation | Relay isolation |
| OFF Delay Time | 10ms or less |
| Weight | Approx. 290g |
CC-link Module Keyence KV-RC16BR (16 ngõ ra relay)
SKU: KV-RC16BR
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Báo giá
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|
