| Thông số | Giá trị |
|---|---|
| Model | PR-MB30N1 |
| Type | Reflective (Background suppression) |
| Output | NPN |
| Shape | Mini-slim |
| Cable connection | 1 m cable |
| Detection distance | 1 to 30 mm0.039″ to 1.181″ |
| Number of control outputs | 2 outputs |
| Output operation – Output 1 | Light-ON |
| Output 2 | Dark-ON |
| Response time – Output 1 | 0.5 ms |
| Output 2 | ON→OFF: 2.7 ms, OFF→ON: 0.5 ms |
| Sensitivity adjustment | None |
| Spot diameter | Approx. ø5.5 mm (at 30 mm) |
| Light source | 4 element, point light source, red LED (650 nm) |
| Mutual interference prevention function | 4 sensors |
| Indicator lamp | Output indicator (orange), stable operation indicator (green), thrubeam type transmitter: power supply indicator (green) |
| Control output | 30 VDC or lower, 50 mA or lowerLeakage current:When 3 kΩ load resistance, 0.3 mA or lower. When 1 kΩ load resistance, 0.5 mA or lower. When 0.2 kΩ load resistance, 1.5 mA or lowerResidual voltage:When 10 mA or lower, 1.0 V or lower. When 10 to 30 mA, 1.5 V or lower. When 30 to 50 mA, 2.0 V or lower. |
| Protection circuit | Power supply reverse connection protection, output overcurrent protection,output surge protection, power supply surge protection |
| Rating – Power voltage | 10 to 30 VDC, including Ripple (P-P) 10 % |
| Current consumption | 19 mA |
| Environmental resistance – Enclosure rating | IP67 (IEC60529), IP69K (DIN40050-9), 4X, 6P, 13 (NEMA250) |
| Insulation resistance | 20 MΩ or higher (500 VDC) |
| Ambient light | Incandescent lamp: 5,000 lux or lower, Sunlight: 20,000 lux or lower |
| Ambient temperature | -25 to +55 °C-13 to 131 °F(No freezing) |
| Storage temperature | -25 to +75 °C-13 to 167 °F |
| Relative humidity | 35 to 85 % RH (No condensation) |
| Withstand voltage | 1,000 VAC, 50/60 Hz, 1 min |
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance | 1,000 m/s2, 6 times in each of the X, Y, and Z directions |
| Material | Case: SUS316L, indicator cover/lens cover: polysulfone,cord protector: polymethylpentene, filler: polyester-based resin |
| Accessories | Instruction manual |
| Weight | Approx. 21 g |
Cảm biến quang Keyence PR-MB30N1
SKU: PR-MB30N1
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng
1.800.000 ₫
Thông tin bổ sung
| Thương hiệu | Keyence |
|---|---|
| Loại | Cảm biến quang |
