Name: Cảm biến quang Keyence PR-MB15C3PL
Brand: Keyence
SKU: PR-MB15C3PL
Availability: InStock

Cảm biến quang Keyence PR-MB15C3PL

SKU: PR-MB15C3PL
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

1.600.000 ₫

SKU: PR-MB15C3PL Danh mục: Cảm biến Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	PR-MB15C3PL*1
Type	Reflective (Background suppression)
Output	PNP
Shape	Mini-slim
Cable connection	M8 connector (3 pin)
Detection distance	1 to 15 mm0.04″ to 0.59″
Number of control outputs	1 output
Output operation – Output 1	–
Output 2	Light-ON
Response time – Output 1	–
Output 2	ON→OFF: 2.7 ms, OFF→ON: 0.5 ms
Sensitivity adjustment	None
Spot diameter	Approx. ø3 mm (at 15 mm)
Light source	4 element, point light source, red LED (650 nm)
Mutual interference prevention function	4 sensors
Indicator lamp	Output indicator (orange), stable operation indicator (green), thrubeam type transmitter: power supply indicator (green)
Control output	30 VDC or lower, 50 mA or lowerLeakage current:When 3 kΩ load resistance, 0.3 mA or lower. When 1 kΩ load resistance, 0.5 mA or lower. When 0.2 kΩ load resistance, 1.5 mA or lowerResidual voltage:When 10 mA or lower, 1.0 V or lower. When 10 to 30 mA, 1.5 V or lower. When 30 to 50 mA, 2.0 V or lower.
Protection circuit	Power supply reverse connection protection, output overcurrent protection,output surge protection, power supply surge protection
Rating – Power voltage	10 to 30 VDC, including 10 % ripple (P-P)
Current consumption	19 mA
Environmental resistance – Enclosure rating	IP67 (IEC60529), 4X, 6P, 13 (NEMA250)
Insulation resistance	20 MΩ or higher (500 VDC)
Ambient light	Incandescent lamp: 5,000 lux or lower, Sunlight: 20,000 lux or lower
Ambient temperature	-25 to +55 °C-13 to 131 °F(No freezing)
Storage temperature	-25 to +75 °C-13 to 167 °F
Relative humidity	35 to 85 % RH (No condensation)
Withstand voltage	1,000 VAC, 50/60 Hz, 1 min
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions
Shock resistance	1,000 m/s2, 6 times in each of the X, Y, and Z directions
Material	Case: SUS316L, indicator cover/lens cover: polysulfone,cord protector: polymethylpentene, filler: polyester-based resin
Accessories	Instruction Manual
Weight	Approx. 13 g
