Name: Cảm biến quang Keyence PR-G61N
Brand: Keyence
SKU: PR-G61N
Availability: InStock

Thông số	Giá trị
Model	PR-G61N
Type	Retro-reflective
Shape	Rectangular
Output	NPN
Cable connection	2 m cable
Detecting distance	0.1 to 4.2 m0.3′ to 13.8′(when using R-2L)
Number of control outputs	2 (Dark-ON +Light ON)*1
Output operation – Output 1	Dark-ON
Output 2	Light-ON*2
Response time	0.5 ms
Sensitivity adjustment	Five-turn trimmer
Spot diameter	―
Light source	4 elements, Red LED (630 nm)
Light interference prevention function	2
Indicator lamp	7 segment display (0 to 999), output indicator (yellow)
Control output	NPN open collector30 VDC or less, 100 mA or lessResidual voltage: 1.2 V or less at less than 10 mA, 2 V or less at 10 to 100 mA
Stop emission input	―
Protection circuit	Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection
Rating – Power voltage	10 to 30 VDC, including Ripple (P-P) 10 %
Power consumption	450 mW max. (15 mA max. at 24 V, 21 mA max. at 12 V)
Environmental resistance – Enclosure rating	IP68 (IEC60529), IP69K (DIN40050-9),4X, 6P, 13 (NEMA250)*3
Insulation resistance	20 MΩ or more (500 VDC)
Ambient light	Incandescent lamp: 5,000 lux or less, Sunlight: 20,000 lux or less
Ambient temperature	-20 to +70 °C-4 to 158 °F(No freezing)*4
Storage temperature	-20 to +70 °C-4 to 158 °F
Relative humidity	35 to 85 % RH (No condensation)
Withstand voltage	1,000 VAC, 50/60 Hz, 1 min
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions
Shock resistance	1,000 m/s2, 6 times in each of the X, Y, and Z directions
Material	Case: SUS 316L,Indicator cover: PES,7-segment display cover/Lens cover: PMMA (scratch-resistant coating)M18 nut: Brass (Nickel plating),Lock washer: Steel (Chrome plating)
Accessories	Instruction manual
Weight	Approx. 75 g

Thông tin bổ sung

Thương hiệu	Keyence
Loại	Cảm biến quang

Cảm biến quang Keyence PR-G61N
