Name: Cảm biến quang Keyence PR-G41CBL
Brand: Keyence
SKU: PR-G41CBL
Availability: InStock

Cảm biến quang Keyence PR-G41CBL

SKU: PR-G41CBL
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

2.800.000 ₫

SKU: PR-G41CBL Danh mục: Cảm biến Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	PR-G41CBL
Type	Diffuse reflective (Long distance)
Shape	Threaded mount type
Output	NPN+PNP
Cable connection	M12 connector (4 pin)
Detecting distance	500 mm19.685″
Number of control outputs	2 (NPN+PNP)
Output operation – Output 1	Light-ON
Output 2	Dark-ON*1
Response time	0.5 ms
Sensitivity adjustment	Five-turn trimmer
Spot diameter	ø20 mmø0.79″max.(at 300 mm11.81″)
Light source	4 elements, Point light source red LED (650 nm)
Light interference prevention function	2
Indicator lamp	7 segment display (0 to 999), output indicator (yellow)
Control output	NPN + PNP open collector30 VDC or less, 100 mA or lessResidual voltage: 1.2 V or less at less than 10 mA, 2 V or less at 10 to 100 mA
Stop emission input	―
Protection circuit	Protection against reverse power connection, power supply surge, output overcurrent, output surge, and reverse output connection
Rating – Power voltage	10 to 30 VDC, including Ripple (P-P) 10 %
Power consumption	450 mW max. (15 mA max. at 24 V, 21 mA max. at 12 V)
Environmental resistance – Enclosure rating	IP68 (IEC60529), IP69K (DIN40050-9), 4, 6, 13 (NEMA250)*2
Insulation resistance	20 MΩ or more (500 VDC)
Ambient light	Incandescent lamp: 5,000 lux or less, Sunlight: 20,000 lux or less
Ambient temperature	-20 to +70 °C-4 to 158 °F(No freezing)*3
Storage temperature	-20 to +70 °C-4 to 158 °F
Relative humidity	35 to 85 % RH (No condensation)
Withstand voltage	1,000 VAC, 50/60 Hz, 1 min
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions
Shock resistance	1,000 m/s2, 6 times in each of the X, Y, and Z directions
Accessories	Instruction Manual, M18 nut, Lock washer
Weight	Approx. 45 g
