Name: Cảm biến nhiệt độ Keyence FT-H20
Brand: Keyence
SKU: FT-H20
Availability: InStock

Cảm biến nhiệt độ Keyence FT-H20

SKU: FT-H20
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

6.500.000 ₫

SKU: FT-H20 Danh mục: Cảm biến Keyence Thương hiệu: Keyence

Thông số	Giá trị
Model	FT-H20
Type	Mid to low temperature, Mid-range
Rated temperature range	0 to 500°C32 to 932°F*1
Displayable temperature range	-50 to +520°C-58 to +968°F
Detecting distance	Unlimited*2
Measuring distance /View diameter (example)	60/ø8.5 mm2.36″/ø0.33″120/ø6 mm4.72″/ø0.24″180/ø14.5 mm7.09″/ø0.57″
Sight	2-point visible laser beam*3
Detecting element	Thermopile
Detecting wavelength	8 to 14 µm
Repeatability	±0.5°C0.9°F
Emissivity (ε) correction	0.10 to 1.99 (0.01 step)
Environmental resistance – Ambient temperature	-10 to +55 °C14 to 131 °F(No freezing)
Relative humidity	35 to 85 % RH (No condensation)
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z axis
Shock resistance	500 m/s2, 10 times in each direction of each of X, Y and Z axis, 60 times in total
Material	Case: Reinforced glass plastic, Infrared collector lens: Germanium, Laser transmitter: PolyarylateCable: Vinyl chloride, Mounting bracket: SUS304, Mounting screw: Stainless steel
Accessory	Mounting bracket
Weight	Approx. 120 g
