Cảm biến lưu lượng Keyence FD-XS8

Cảm biến lưu lượng Keyence FD-XS8

SKU: FD-XS8
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

Báo giá
SKU: FD-XS8 Danh mục: Thương hiệu:
Thông số Giá trị
Model FD-XS8
Supported pipe materials Metal pipes, Plastic pipes (soft/hard)*1
Supported fluids Liquids (water, oil, adhesive, grease, chemical solutions, etc.)*1
Supported fluid temperature 0 °C (no freezing on the pipe surface) to 100 °C32 to 212 °F(Pipe surface temperature)
Clamp set model – Plastic pipe/tube attachment FD-XC8R1, FD-XC8R2, FD-XC8R3
Metal pipe attachment FD-XC8M*2
Maximum rated flow rate Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : 0 to 3000 mL/minOuter diameter of pipe ø 80.31 “: 0 to 8000 mL/min
Zero cut flow rate 40 mL/min*3(variable, default)
Display resolution – Instantaneous flow rate 0.1/1/10 mL/min (Displayed on controller)
Shot amount 0.001/0.01/0.1/1 mL (Displayed on controller)
Repeatability – Plastic pipe/tube attachment – Response time: 50 ms – F.S. ± 0.1 %*4*5
Instantaneous flow rate Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : ±3 mL/minOuter diameter of pipe ø 80.31 “: ±8 mL/min*4*5
Response time: 500 ms Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : ±1.0 mL/minOuter diameter of pipe ø 80.31 “: ±2.6 mL/min*4
Metal pipe attachment – Response time: 50 ms – F.S. Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : ±0.3 %Outer diameter of pipe ø 80.31 “: ±0.15 %*4*5
Instantaneous flow rate Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : ±9 mL/minOuter diameter of pipe ø 80.31 “: ±12 mL/min*4*5
Response time: 500 ms Outer diameter of pipe ø 60.24 “, 1/4 ” (6.35 mm) : ±2.9 mL/minOuter diameter of pipe ø 80.31 “: ±3.8 mL/min*4
Hysteresis Variable
Integrated unit display 0.1/1/10/100/1000/10000 mL (displayed on controller)
Display method Status indicator
Environmental resistance – Enclosure rating IP65/IP67 (IEC60529) , IP68G (JIS C0920)*6
Ambient temperature -10 to 60 °C (No freezing)14 to 140 °F
Relative humidity 35 % to 85 %RH (No condensation)
Vibration resistance 10 to 55 Hz, double amplitude 1.5 mm0.06 “, 2 hours each for X,Y,Z direction
Shock resistance 50 G 11 ms 3 times each for X,Y,Z direction
Material – Sensor head Head body: PPS/PPSU, in-cable amplifier: PPS, cable: PVC, controller connector: PPS/PBT/POM
Clamp set – For plastic pipe Body, fixing screw: PPS, detection surface: special rubber, pipe support rubber: FKM, sensor head fixing screw: SUSXM7
For metal pipe Metal: SUS304/SUSXM7, detection surface: special rubber, clamp support rubber: FKM, sensor head fixing screw: SUSXM7
Weight Approx. 250 g

Thông tin bổ sung

Thương hiệu

Keyence
Loại

Cảm biến lưu lượng

Khu vực Miền Nam
