Cảm biến lưu lượng Keyence FD-XS20

Cảm biến lưu lượng Keyence FD-XS20

SKU: FD-XS20
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

Báo giá
SKU: FD-XS20 Danh mục: Thương hiệu:
Thông số Giá trị
Model FD-XS20
Supported pipe materials Metal pipes, Plastic pipes (soft/hard)*1
Supported fluids Liquids (water, oil, adhesive, grease, chemical solutions, etc.)*1
Supported fluid temperature 0 °C (no freezing on the pipe surface) to 100 °C32 to 212 °F(Pipe surface temperature)
Clamp set model – Plastic pipe/tube attachment FD-XC20R1, FD-XC20R2, FD-XC20R3, FD-XC20R4
Metal pipe attachment FD-XC20M1, FD-XC20M2*2
Maximum rated flow rate Outer diameter of pipe 3/8 ” (9.53 mm) , ø 100.39 “, ø 10.50.41 “: 0 to 15.00 L/minOuter diameter of pipe ø 120.47 “, 1/2 ” (12.7 mm) , ø 13.80.54 “: 0 to 20.00 L/min
Zero cut flow rate 0.10 L/min (standard), 40 mL/min (high resolution*3)*4(variable, default)
Display resolution – Instantaneous flow rate 0.001/0.01/0.1 L/min (standard), 0.1/1/10 mL/min (high resolution*3) (Displayed on controller)
Shot amount 0.001/0.01/0.1 L (standard), 0.001/0.01/0.1/1 mL (high resolution*3) (Displayed on controller)
Repeatability – Plastic pipe/tube attachment – Response time: 50 ms – F.S. ± 0.1 %*5*6
Instantaneous flow rate Outer diameter of pipe 3/8 ” (9.53 mm) , ø 100.39 “: ±15 mL/minOuter diameter of pipe ø 120.47 “, 1/2 ” (12.7 mm): ±20 mL/min*5*6
Response time: 500 ms Outer diameter of pipe 3/8 ” (9.53 mm) , ø 100.39 “: ±4.7 mL/minOuter diameter of pipe ø 120.47 “, 1/2 ” (12.7 mm): ±6.3 mL/min*5
Metal pipe attachment – Response time: 50 ms – F.S. ±0.15 %*5*6
Instantaneous flow rate Outer diameter of pipe 3/8 ” (9.53 mm) , ø 100.39 “, ø 10.50.41 “: ±23 mL/minOuter diameter of pipe ø 120.47 “, 1/2 ” (12.7 mm) , ø 13.80.54 “: ±30 mL/min*5*6
Response time: 500 ms Outer diameter of pipe 3/8 ” (9.53 mm) , ø 100.39 “, ø 10.50.41 “: ±7.2 mL/minOuter diameter of pipe ø 120.47 “, 1/2 ” (12.7 mm) , ø 13.80.54 “: ±9.5 mL/min*5
Hysteresis Variable
Integrated unit display 0.01/0.1/1/10/100 L (standard), 0.1/1/10/100/1000/10000 mL (high resolution*3) (displayed on controller)
Display method Status indicator
Environmental resistance – Enclosure rating IP65/IP67 (IEC60529) , IP68G (JIS C0920)*7
Ambient temperature -10 to 60 °C (No freezing)14 to 140 °F
Relative humidity 35 % to 85 %RH (No condensation)
Vibration resistance 10 to 55 Hz, double amplitude 1.5 mm0.06 “, 2 hours each for X,Y,Z direction
Shock resistance 50 G 11 ms 3 times each for X,Y,Z direction
Material – Sensor head Head body: PPS/PPSU, in-cable amplifier: PPS, cable: PVC, controller connector: PPS/PBT/POM
Clamp set – For plastic pipe Body, fixing screw: PPS, detection surface: special rubber, pipe support rubber: FKM, sensor head fixing screw: SUSXM7
For metal pipe Metal: SUS304/SUSXM7, detection surface: special rubber, clamp support rubber: FKM, sensor head fixing screw: SUSXM7
Weight Approx. 260 g
