Name: Cảm biến lưu lượng Keyence FD-Q32C
Brand: Keyence
SKU: FD-Q32C
Availability: InStock

Thông số	Giá trị
Model	FD-Q32C
Supported pipe diameter	1″ (25 A), ø28 to ø37 (mm)1 1/4″ (32 A), ø37 to ø44 (mm)
Supported pipe materials	Metal pipe/Resin pipe*1
Supported fluids	Various liquid [i.e. water (including DI), oils, chemicals, etc.]*1
Supported fluid temperature	0 to 85°C32 to 185°F(No freezing on the pipe surface)*2
Maximum rated flow	1″ (25 A): 200 L/min, 52.8 G/min1 1/4″ (32 A): 300 L/min, 79.3 G/min
Zero cut flow rate	5 L/min (Default)*3
Display method	Status indicator, output indicator, dual row display with 4-digit, 7 segment LED, stability level indicator
Display update cycle	Approx. 3 Hz
Display resolution	0.1/ 1 (Default :1) (L/min)
Response time	0.5 s / 1.0 s / 2.5 s / 5 s / 10 s / 30 s / 60 s
Protection circuit	Power supply reverse connection protection, power supply surge protection,each output short-circuit protection, each output surge protection
Repeatability	0.5 s : ±2.0%, 1 s:±1.5%, 2.5 s : ±1.0%, 5 s : ±0.5%, 10 s : ±0.35%, 30 s : ±0.2%, 60 s : ±0.15% (/F.S.*4(Specific to selected response time))
Hysteresis	Variable
Integrated flow unit display	1/ 10/ 100/ 1000/ 10000 (Default : 1) (L)
Integrated flow data storage cycle	Save to memory every 10 seconds
Memory backup	EEPROM (Data storage length: 10 years or longer, Data read/write frequency: 1 million times or more)
Power I/O connector	M12 4-pin connector
Input/Output (Selectable) – Output (ch.1/ch.2)	Control output/ Pulse output/ Error output (Selectable, Default : ch.1 control output/ ch.2 not used),NPN/PNP setting switchable,open collector output 30 V or less, max. 100 mA/ch., residual voltage 2.5 V or less*5
Analog output (ch.1/ch.2)	4 to 20 mA / 0 to 20 mA (Selectable, Default: not used), load resistance 500 Ω or less*5
External input (ch.2)	Integrated flow reset input/ Flow rate zero input/ Origin adjustment input (Selectable, Default: not used),short-circuit current 1.5 mA or less, input time 20 ms or more*5
Power supply – Power voltage	20 to 30 VDC , ripple (P-P) 10% max, Class2/LPS
Current consumption	130 mA or less (Load current excluded)*6
Environmental resistance – Enclosure rating	IP65/IP67 (IEC60529)
Ambient temperature	-10 to +60 °C14 to 140 °F(No freezing)
Relative humidity	35 to 85 % RH (No condensation)
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions
Shock resistance	100 m/s2, 16 ms pulse, 1,000 times in each of the X, Y, and Z directions
Material – Sensor main unit	PPS/PES/PBT/SUS303/SUS304/SUSXM7
Sensor surface	Rubber
Mounting bracket	SUS304/PA/POM/SUSXM7
Weight	Approx. 530 g (including mounting bracket)
