Cảm biến lưu lượng Keyence FD-MZ100ATKP

Cảm biến lưu lượng Keyence FD-MZ100ATKP

SKU: FD-MZ100ATKP
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

Báo giá
SKU: FD-MZ100ATKP Danh mục: Thương hiệu:
Thông số Giá trị
Model FD-MZ100ATKP*1
Type Vertical
Shape Built-in amplifier
Rated flow range 1.4 – 26.0 G/min (5.0 – 100 L/min)*1
Possible display range 1.4 – 52.8 G/min (5.0 – 200 L/min)*2
Possible ranges to set 0 – 52.8 G/min (0 – 200 L/min)
Connection port NPT1 (25 A)
Detectable fluids Water or non-corrosive liquid
Conductivity of detection fluids 5 µS/cm or higher
Detection fluid temperature 0 to +85°C32 to 185 °F(No freezing)
Pressure loss Max. 1.45 PSI (0.01 MPa)
Display method Dual row display with 4-digit, 7 segment LED, bar display (2 colors), output indicators, flow indicator
Display resolution 0.1/1 (G/min, L/min) selectable
Repeatability 0.5 s : ±5% of F.S., 1 s : ±3.5% of F.S., 2.5 s : ±2.5% of F.S., 5 s : ±1.6% of F.S., 10 s : ±1% of F.S., 30 s : ±0.8% of F.S., 60 s : ±0.6% of F.S.*3
Hysteresis Variable
Response time (chatter prevention feature) 0.5 s/1 s/2.5 s/5 s/10 s/30 s/60 s variable
Accumulated flow unit 0.1/1/10/100/1000 (G, L) selectable
Integration data storage cycle Save to memory every 10 seconds
Memory backup EEPROM (Data storage length : 10 years or longer, Data read/write frequency : 1 million times or more)
Control output/Accumulation pulse output/ Error alarm output PNP open collector, max. 100 mA/ch*430 V or less,residual voltage 1 V or less, 3 outputs (N.O./N.C. switchable)
Analog output 4-20 mA, max. load resistance 260 Ω Analog output range can be set to any value
Integration reset/bank switch input/flow zero function input Input time : 20 ms or greater,Select either the accumulation output or the accumulation pulse by setting the mode
Minimum flow volume 1.4 G/min (5 L/min)*5
Power consumption (Current consumption) Normal : 1700 mW (70 mA), Power save : 1000 mW (40 mA)
Rating – Power voltage 24 VDC, Ripple (P-P) 10 % or less, Class 2
Environmental resistance – Enclosure rating IP65
Pressure resistance 290 PSI (2.0 MPa)
Applied pressure range Max. 145 PSI (1.0 MPa)
Ambient temperature 0 to +50 °C32 to 122 °F(No freezing)
Relative humidity 35 to 85 % RH (No condensation)
Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm0.06″, 2 hours in each of the X, Y, and Z directions
Material – Liquid end materials Bore : SCS13, Measurement pipe : PPS, O ring : fluoro-rubber (FKM)
Other materials Plastic case areas : PPS, Metal case areas : SUS430, Cable : PVC
Accessory Instruction Manual, Connector cable (2.7 m106.3″)
Weight Approx. 1,340 g
