Name: Bộ khuếch đại cảm biến Keyence FT-50A
Brand: Keyence
SKU: FT-50A
Availability: InStock

Bộ khuếch đại cảm biến Keyence FT-50A

SKU: FT-50A
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

5.500.000 ₫

SKU: FT-50A Danh mục: Cảm biến Keyence Thương hiệu: Keyence

Thông số	Giá trị
Type	DIN-rail mounting type
Rating – Power voltage	12 to 24 V DC ±10% ripple (P-P) 10% or less
Power consumption – Normal	1400 mW (For 12 V), 1600 mW (For 24 V)
Powerconsumption – Eco mode	1150 mW (For 12 V), 1350 mW (For 24 V)
Display power	4 + 1/two-digit 7-segment LED, dual-display (red/green) display
Operation indicator	Red LED x 3 (control output1/control output2/timing input indicator)
Display resolution	0.1°C or 1°C (when using the FT-H10/H20/H30), 1°C (when using the FT-H50/H40K/H50K)
Hysteresis	Variable
Response	HSP, 30, 100, 200, 500, 1000, or 5000 ms can be selected (In HSP: 10ms typ., 15 ms max.)
Bank selection	Switch from the timing input line and analog output line to bank input, up to 4 banks can be set
Bank specifications	For each bank, emissivity (during temperature mode) and the set value × 2 can be set
External input – Timing input	Input time: 2 ms min.
Bank input	Input time: 20 ms min.
Control output	NPN open collector x 2 channels (N.O./N.C. selectable), 100 mA max. (40 VDC max.), residual voltage: 1 V max.
Analogue output	4 to 20 mA, maximum load resistance: 260 Ω The upper- and lower-limit values of the analog output range can be set optionally.
Environmental resistance – Ambient temperature	-10 to +50 °C (No freezing)*1
Relative humidity	35 to 85 % RH (No condensation)
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z axis
Material	Main unit, Cover: Polycarbonate
Accessories	DIN fixing bracket, power cable, unit cover sticker
Weight	Approx. 85 g
