Bộ khuếch đại cảm biến Keyence FS-MC8P

Thông số	Giá trị
Model	FS-MC8P
Output	PNP
Response time	Depends on the response time settings of the connected expansion units
External input	Input time of the connected expansion units +11 ms
Number of inputs and outputs	Separate control outputs: 8, common output: 1, common input: 1
Unit expansion	Up to 8 expansion units can be connected. (However, each dual output type will be treated as 2 expansion units.) Allowable passing current: 1200 mA or less
Indicators	STATUS indicator (green and red two-color display) MEMORY indicator (orange) LOCK indicator (orange)
Separate control output,common output	PNP open-collector, 30 V or less, 20 mA or less per output, residual voltage: 1.6 V or less
Protection circuit	Protection against reverse power connection, reverse output connection, output overcurrent, and output surge
Power supply – Power voltage	10 to 30 VDC (including 10 % ripple (P-P) or less) , class 2 or LPS*1
Power consumption	690 mW or less (when used as a solitary unit) (26 mA or less at 24 V/38 mA or less at 12 V [excluding the load current] )*2
Environmental resistance – Ambient temperature	-20 °C-4 °Fto +55 °C+131 °F(no freezing)
Vibration resistance	10 to 55 Hz; double amplitude 1.5 mm0.06″; 2 hours each for X, Y, and Z axes
Shock resistance	500 m/s2; 3 times each for X, Y, and Z axes
Case material	Main unit and cover: polycarbonate
Weight	Approx. 110 g

Thông tin bổ sung

Thương hiệu	Keyence
Loại	Cảm biến quang
