Bộ điều khiển camera Keyence KV-CA02

Bộ điều khiển camera Keyence KV-CA02

SKU: KV-CA02
Hãng sản xuất: Keyence
Công nghệ: Nhật Bản
Chất lượng: Mới 100%
Bảo hành: Chính hãng

Báo giá
SKU: KV-CA02 Danh mục: Thương hiệu:
Thông số Giá trị
Model KV-CA02*1
General specifications – Power voltage System configuration using an expansion unit for KV-5000/3000 Series: 24 VDC (±10%)*2System configuration using an expansion unit only for KV-8000/7000 Series: 24 VDC (-15%/+20%)*2
Operating ambient temperature System configuration using an expansion unit for KV-5000/3000 Series: 0 to +50°C32 to 122°F(no freezing)*3*4System configuration using an expansion unit only for KV-8000/7000 Series: 0 to +55°C32 to 131°F(no freezing)*3*4
Operating ambient humidity System configuration using an expansion unit for KV-5000/3000 Series: 10 to 95% RH(no condensation)*3System configuration using an expansion unit only for KV-8000/7000 Series: 5 to 95% RH(no condensation)*3
Storage ambient temperature System configuration using an expansion unit for KV-5000/3000 Series: -20 to +70°C-4 to +158°F*3System configuration using an expansion unit only for KV-8000/7000 Series: -25 to +75°C-13 to +167°F*3
Storage relative humidity System configuration using an expansion unit for KV-5000/3000 Series: 10 to 95% RH(no condensation)*3System configuration using an expansion unit only for KV-8000/7000 Series: 5 to 95% RH(no condensation)*3
Operating environment No dust or corrosive gas
Operating altitude 2000 m6561.7′or less
Noise immunity 1500 Vp-p or morePulse duration: 1 μs, 50 ns (based on noise simulator)IEC standard-compliant (IEC 61000-4-2/3/4/6)
Withstand voltage 1500 VAC for one minute (between the power terminals and the I/O terminals, and between the external terminals and the case)
Insulation resistance 50 MΩ or more (between the power terminals and the I/O terminals and between the external terminals and the case, with 500 VDC megohmmeter)
Vibration resistance – Intermittent vibration – Frequency 5 to 9 Hz Half amplitude 3.5 mm0.14″*5
Frequency 9 to 150 Hz Acceleration 9.8 m/s232.2’/s2*5
Continuous vibration – Frequency 5 to 9 Hz Half amplitude 1.75 mm0.07″*5
Frequency 9 to 150 Hz Acceleration 4.9 m/s216.1’/s2*5
Shock resistance Acceleration: 150 m/s2492.1’/s2, Application time: 11 ms, 2 times in each of the X, Y, and Z directions
Pollution degree 2
Performance specifications – Connectable CPU unit KV-8000A
Max. number of connectable units 4
Number of ports 2
Supported camera models KV-CA1H (Compact standard camera)KV-CA1W (Wide-field high-resolution camera)
Cable length 5/10/20 m16.4’/32.8’/65.6′*6
Recording time Approx. 3 minutes*7
Internal current consumption 260 mA or less*8
Weight Approx. 190 g
